ROCKY MOUNTAIN 2024 - INSTINCT C70

In search of a quiver-killer? We’ve got you covered. Designed to thrive on technical trails, but still allows you to push the distance and crush the climbs.

The Instinct Carbon is at home on technical trails, but still allows you to push the distance and crush the climbs. Our most versatile platform just got more adventure-ready with updated the frame features, geometry, and suspension kinematics to make sure you feel confident on the up’s, down’s, and everything in between. Meet the Instinct Carbon.

Frame: SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 140mm Travel. SMOOTHWALL™ Carbon Rear Triangle
Fork:Fox 36 Float EVOL GRIP2 Performance Elite Series 150mm | 27.5 = 37mm Offset | 29 = 44mm Offset
Front Travel:150
Rear Shock:Fox Float X Performance Elite | Sealed Bearing Eyelet | 20x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ
Rear Travel:140
Headset:FSA Orbit NO.85 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Durable Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Stem:Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm
Handelbar:Rocky Mountain AM Carbon 780mm
Grips:ODI Elite Pro Lock On
Brakes:Shimano XT Trail 4 Piston | Metal Pads
Shifters:Shimano XT
Rear Derailleur:Shimano XT
Cranks & Chainring:Race Face Turbine Cinch | 32T | 30mm Spindle | Crankarm Length: XS - SM = 165mm | MD - XL = 170mm
Bottom Bracket:Race Face BB92 30mm
Cassette:Shimano XT 10-51T
Chain:Shimano M8100
Front Hub:Rocky Mountain SL Sealed Boost 15mm
Rear Hub:DT Swiss 370 Boost 148mm | 18T Star-Ratchet
Spokes:DT Swiss Competition 2.0/1.8/2.0
Rims:Race Face AR 30 | 28H / Tubeless Ready - Tape / Valves Incl
Tires:F: Maxxis Dissector 2.4 WT 3C MaxxTerra EXO Tubeless Ready // R: Maxxis Dissector 2.4 WT 3C MaxxTerra EXO Tubeless Ready
Seatpost:Race Face Turbine R (by Fox) Dropper 30.9mm | XS = 125mm | SM = 150mm | MD = 175mm | LG - XL = 200mm
Saddle:WTB Volt Race 142
